Eurotec EPE2M01 Wave Series Limit Switchbox
£71.00 plus VAT
Only 1 left in stock
Description
The Eurotec EPE2M01 Wave Series Limit Switchbox is a reliable and versatile valve position feedback unit designed for industrial process control applications. Built with a durable PA/PC enclosure, it offers a lightweight yet robust solution that withstands demanding operating environments while providing excellent resistance to impact and corrosion.
The switchbox features a NAMUR stainless steel shaft and an adjustable stainless steel mounting bracket, ensuring smooth, accurate actuation and compatibility with a wide range of quarter-turn valve actuators. Its compact design supports easy installation and long-term mechanical stability.
Equipped with a ZF D44X SPDT mechanical microswitch, the EPE2M01 provides precise and dependable open/close position signalling. With a strong switching capacity of 10 A at 250 V AC and 2.5 A at 24 V DC, it is suitable for both AC and DC control systems. The device supports SIL 1–3 requirements, making it appropriate for safety-related applications.
A factory-fitted M20×1.5 cable gland ensures secure wiring and a watertight seal, enhancing reliability in outdoor and industrial conditions. Rated to IP67, the unit is fully protected against dust and temporary water immersion.
Additional information
